Hydraulic Adjustable Loading Dock Ramp



The hydraulic adjustable loading dock ramp is generally used together with the forklift to loading and unloading cargo from the truck.


Product Detail

Product Tags

The hydraulic adjustable loading dock ramp is generally used together with the forklift to loading and unloading cargo from the truck.

The movable forklift loading dock ramp is like a moveable bridge that allow the forklift to drive into a truck compartment from any solid ground, it can be operated by a single person easily, so the warehouse loading dock ramp is efficient to save much labor cost.

5-yard-ramp-xq-1

Parameters of Loading Dock Ramp:

1.Table length:2800mm

2.Slope floor length:8200mm

3.Lip length:300mm

4.Outer width(total width):2100mm

5.Inner width(for forklift to pass):1810mm

6.Adjustable height:1.2m-1.7m

5-yard-ramp-xq-2
