Affordable Easy-Install Metal Slotted Angle Shelving
Slotted angle shelving is a versatile and economical storage solution commonly used in warehouses, offices, and homes. Designed to accommodate large quantities of small and lightweight items, this system offers a practical way to organize daily operations while maximizing available space.
Constructed from high-quality steel and protected with a durable powder-coated finish, the shelving provides enhanced resistance to corrosion, scratches, and long-term wear. Its strong and stable structure ensures reliable performance even under frequent use.
One of the key advantages of slotted angle shelving is its easy installation process. Since it requires minimal hardware—and in many cases only a wooden mallet—it allows users to assemble or reconfigure the unit quickly without technical expertise. This makes it ideal for businesses that frequently adjust their storage layout.
Slotted angle shelving is also highly customizable. With a wide range of lengths, depths, and heights available (see size chart below), it can be adapted to suit different storage requirements. Each shelf can support loads ranging from 50 kg to 100 kg, depending on the steel thickness selected.
Speicifications
| TYPE | LENGTH | DEPTH | HEIGHT | THICK (MM) | LOAD CAPACITY |
| aceshelf-1 | 900 | 300 | 2400 & 3000 | 0.7 | 55 kg |
| 0.8 | 65 kg | ||||
| 1 | 110 kg | ||||
| aceshelf-2 | 900 | 450 | 2400 & 3000 | 0.6 | 40-50 kg |
| 0.8 | 50-60 kg | ||||
| 1 | 80-100 kg | ||||
| aceshelf-3 | 900 | 600 | 2400 & 3000 | 0.6 | 40-50 kg |
| 0.8 | 50-60 kg | ||||
| 1 | 80-100 kg |
Benefits
●Quick access to products from all sides
●Easy to assemble and disassemble
●Customized to meet storage needs
●Cost-effective and easy to handle
●Sturdy angles for light and heavy items
